PAPR Laser Welding Replacement Face Plates | Shade 3, Shade 5 & 417

Roll over image to zoom in Click on image to zoom

PAPR Laser Welding Replacement Face Plates | Shade 3, Shade 5 & 417

Name: PAPR Laser Welding Replacement Face Plates | Shade 3, Shade 5 & 417
Brand: Laser Safety Industries
Price: 175.00 USD
Availability: InStock

Laser Safety IndustriesSKU: LC-S5-PLATE

Configuration: Laser Cleaning No Weld Flash Protection (100-417)

Variant

Price:

$175.00

Quantity:

🚚In stock items ship same or next day | Typically delivered in 1–2 business days | Overnight shipping available—call for timing

Tax exempt? Apply at checkout. W-9 / Vendor / ACH docs here ›

Optical Density

Understanding Optical Density

Visible Light Transmission

Understanding Visible Light Transmission

Frequently Asked Laser Welding Questions

View our Laser Welding Safety FAQ for information related to laser welding systems and associated safety considerations.

View our Laser Welding Safety Guide for a complete overview of face protection, and containment systems.

Explore our Laser Cleaning Safety Resources for additional articles on containment systems, face protection, weld-flash considerations, and industrial fiber laser cleaning safety.

Explore our Laser Cleaning Safety Resource Center for guidance on laser cleaning face shields, respiratory protection systems, process visibility, barriers, and containment solutions.

The PAPR Laser Welding & Cleaning Replacement Face Plates are designed for industrial laser applications and are available in three lens configurations: Weld Flash Shade 3, Weld Flash Shade 5, and Laser Cleaning 417.

These replacement face plates are designed for use with compatible RPB® Z-Link® face shield systems, allowing operators to replace an existing lens plate without purchasing an entirely new helmet or PAPR system.

Each lens configuration provides different optical characteristics to accommodate various laser welding, laser cleaning, and industrial processing applications.

Available Face Plate Options

Laser Cleaning 417

Optical Density(OD)

OD 5+ @ 190-375 nm
OD 5+ @ 860-3300 nm
OD 6+ @ 900-2500 nm
OD 6+ @ 2700-3300 nm
OD 7+ @1060-2500 nm
OD 7+ @2720-3300 nm
OD 5+ @ 10,600 nm

Visible Light Transmission

22%

Weld Flash Shade 3

Provides laser radiation protection with a lighter visible shade than Shade 5, allowing greater visibility of the work area during compatible laser welding and cleaning operations.

Optical Density(OD)

OD 6+ @ 190-400 nm
OD 5+ @ 850-2,700 nm
OD 6+ @ 900-2,600 nm
OD 7+ @ 1,000-2,500 nm
OD 6+ @ 9,000-11,000nm

Visible Light Transmission

18%

Weld Flash Shade 5

Provides laser radiation protection with increased visible brightness reduction compared to Shade 3. Designed for applications where additional shading may improve operator comfort during bright laser processing operations.

Optical Density(OD)

OD 6+ @ 190-400nm
OD 5+ @ 850-2,700 nm
OD 7+ @ 1,000-2,500 nm
OD 8+ @ 1,200-2,450 nm
OD 6+ @ 9,000-11,000nm

Visible Light Transmission

2%

A specialized laser safety filter designed for compatible industrial laser cleaning applications. Provides wavelength-specific laser radiation protection with different optical characteristics than the Weld Flash Shade 3 and Shade 5 configurations.

Features

Three available lens configurations: Shade 3, Shade 5, and 417
Designed for compatible RPB® Z-Link® face shield systems
Replacement face plates for existing compatible helmet assemblies
Wavelength-specific laser radiation protection
Options for different visible light transmission requirements
Designed for industrial laser welding and cleaning environments
Allows replacement of the face plate without purchasing an entire PAPR system

Important Compatibility Information

This product includes the selected replacement face plate only. The RPB® Z-Link® face shield, helmet assembly, breathing hose, and powered air-purifying respirator (PAPR) system are not included.

Customers should verify compatibility with their existing RPB® Z-Link® equipment before ordering.

Important Safety Information

Laser welding and cleaning systems can generate hazardous airborne particulates, reflected laser radiation, and bright process emissions depending on the laser wavelength, power level, material interaction, and operating environment.

Each face plate has its own wavelength-specific optical density ratings. Visible shade ratings alone do not establish adequate laser radiation protection.

Always verify the laser wavelength, required optical density, and equipment compatibility before use. Final PPE selection should be reviewed by the on-site Laser Safety Officer (LSO) or qualified safety professional.

If you'd like to use your own shipping account, please provide your carrier name, account number, and shipping type (standard, overnight, etc.) in the "Order Instructions" located in the top right of the Cart page. Simply choose the least expensive shipping option at checkout, and you will be refunded for the shipping costs after your order is processed.

We ship domestically within the United States and internationally (to all countries our carriers ship to—FedEx and UPS). At checkout, you will have shipping options with UPS and FedEx.

Please note: For most international shipments, it is often faster and more cost-effective to use your shipping account due to customs.

You may return most new, unopened items sold and fulfilled by Laser Safety Industries, LLC., within 30 days of delivery. 30% restocking fee applies to all products returned in new or unopened condition. Item's must be returned within 30 business days of purchase. Customized product are subject to a 40% restocking fee if returned within 30 business days of purchase in new condition. Laser Safety Industries is not responsible returned items that are lost or stolen during shipping. Please call us directly at 1-888-392-5106 to arrange return.For items directed to our Returns Center, expect your refund within 4 weeks of giving your package to the return shipper (though in many cases you'll receive the refund sooner). This time period includes:

* 5 to 10 business days for us to receive your return from the shipper

* 3 to 5 business days for us to process your return

* The time it takes your bank to process our refund request.

We'll notify you via e-mail of your refund once we've received and processed the returned item.

Tax-exempt: If you're tax-exempt, their will be a place when you select Add to Cart to provide your tax-exempt exemption and state tax will be removed.

ANSI Z136 & Laser Welding Safety

Industry guidance for laser welding protective equipment, weld-flash protection, and hazard evaluation.

ANSI Z136 Laser Safety Standards

Laser Safety Industries manufactures laser welding safety products designed to support ANSI Z136 laser safety programs and laser controlled area requirements. Product specifications are provided to assist in the selection of appropriate protective equipment based on wavelength, power, and application requirements.

Weld-Flash Protection

Laser welding processes generate intense visible light from the weld zone in addition to hazardous laser radiation. Depending on the application, operators may utilize Shade 3 or Shade 5 weld-flash protection to improve comfort and visibility while maintaining appropriate laser protection.

Hazard Evaluation Requirements

Laser welding safety programs commonly utilize multiple layers of protection, including laser safety eyewear, face shields, windows, barriers, and controlled-area measures. The appropriate combination of protective equipment should be determined through a documented laser hazard evaluation.
